Distal Radius Locking Plate（6H on head）
Distal Radius Locking Plate（6H on head）
Regular price
$58.00 USD
Sale price
$58.00 USD
Regular price
Shipping calculated at checkout.
Available in stock (15)
Have questions about this product?
Leave your WhatsApp contact information, and one of our 17 dedicated sales managers will provide you with a detailed response within 24 hours.
Couldn't load pickup availability
Product Specifications
Indications
- Fixation of distal radius fractures, including complex intra-articular and extra-articular fracture patterns such as Colles, Smith, and Barton fractures.
Material
- Medical Grade Titanium Alloy
Shaft Options
- Available in 2, 3, 4, 5, 6, and 7-hole shaft configurations.
Design Features
- Anatomical Contouring: Pre-contoured volar distal radius plate designed to improve plate-to-bone fit and minimize intraoperative contouring.
- Low-Profile Design: Engineered to minimize soft-tissue irritation and protect adjacent tendons.
- 6-Hole Distal Head: Optimized configuration providing broad distal fragment coverage and subchondral support.
- Double-Row Arrangement: Distal screw layout designed to enhance resistance to rotational and pull-out forces.
- Left and Right Versions: Anatomically specific configurations available.
Compatible Screws
| Screw Code | Screw Type | Diameter |
|---|---|---|
| HC2.7 | Locking Screw | Ø 2.7 mm |
| HA2.7 | Cortical Screw | Ø 2.7 mm |
Surface Finish
- Anodized and electropolished surface treatment for improved surface consistency.
Fixation Mechanism
- Locking Fixation: Designed to provide angular stable fixation for distal radius fracture management.
Sterilization
- Supplied non-sterile as standard. EO sterile packaging available upon request.
Certifications
- CE Marked
- ISO 13485 Quality Management System
Size & Ordering Chart
| REF | Specification | Side | Compatible Screw |
|---|---|---|---|
| RPRYST62HR | 2H | Right | HA2.7 / HC2.7 |
| RPRYST62HL | 2H | Left | HA2.7 / HC2.7 |
| RPRYST63HR | 3H | Right | HA2.7 / HC2.7 |
| RPRYST63HL | 3H | Left | HA2.7 / HC2.7 |
| RPRYST64HR | 4H | Right | HA2.7 / HC2.7 |
| RPRYST64HL | 4H | Left | HA2.7 / HC2.7 |
| RPRYST65HR | 5H | Right | HA2.7 / HC2.7 |
| RPRYST65HL | 5H | Left | HA2.7 / HC2.7 |
| RPRYST66HR | 6H | Right | HA2.7 / HC2.7 |
| RPRYST66HL | 6H | Left | HA2.7 / HC2.7 |
| RPRYST67HR | 7H | Right | HA2.7 / HC2.7 |
| RPRYST67HL | 7H | Left | HA2.7 / HC2.7 |
This distal radius locking plate is designed for anatomical volar fixation with a 6-hole distal head design and 2–7 hole shaft options. It is compatible with Ø2.7 mm locking screws and Ø2.7 mm cortical screws.
